Technical Data
All technical details at a glance.
Specification & dimension. .
|
|
|
|
|---|---|---|
| Wheel & tyre/ Roda & ban | ||
| Wheel Size/ Ukuran roda | 7.50 x 20 | 7.50 x 20 |
| Tyre size/ Ukuran ban | 11.00 x 20 | 11.00 x 20 |
| Engine/ Mesin | ||
| Type/ Tipe | OM 906 LA, 6 Cylinder | OM 906 LA, 6 Cylinder |
| Cylinder volume/ Volume silinder (liter) | 6.37 | 6.37 |
| Max. power/ Kekuatan maksimum (PS/ rpm) | 280/ 2,200 | 280/ 2,200 |
| Max. torque/ Torsi maksimum (Nm/ rpm) | 1,100/ 1,200-1,600 | 1,100/ 1,200-1,600 |
| Transmission/ Transmisi | ||
| Model | G131 - 9 / 14.57-1.00 | G131 - 9 / 14.57-1.00 |
| Type/ Tipe | Manual | Manual |
| Total gears/ Total gigi | 9-speed forward +1-speed reverse | 9-speed forward +1-speed reverse |
| Performance/ Performa | ||
| Max. speed/ Kecepatan maksimum (km/h) | 90 | 90 |
| Gradeability/ Kemampuan menanjak (%) | 76 (crawler) | 76 (crawler) |
| Accu/ Aki | ||
| Power/ Kekuatan | 2x12V, 120 Ah | 2x12V, 120 Ah |
| Clutch/ Kopling | ||
| Type/ Tipe | Dry-single plate, hydraulic actuated control with servo assistance | Dry-single plate, hydraulic actuated control with servo assistance |
| Diameter (mm) | 395 | 395 |
| Fuel Tank/ Tangki BBM | ||
| Volume (liter) | 255 | 255 |
| Power Take-Off (PTO) | ||
| Type/ Tipe | Transmission PTO | Engine PTO |
| Rotation/ Rotasi | 1.35/ clockwise | 0.933/ Counter-clockwise |
| PTO Control/ Kontrol PTO | Electro-Pneumatic | Electro-Pneumatic |
| Front axle/ Sumbu depan | ||
| Max. capacity/ Kapasitas beban maksimum (kg) | 6,500 | 6,500 |
| Rear axle/ Sumbu belakang | ||
| Max. capacity/ Kapasitas beban maksimum (kg) | 20,000 (10,000 +10,000) | 20,000 (10,000 +10,000) |
| Final gear ratio/ Perbandigan gigi terakhir | 5.375 | 5.375 |
| Diff. lock | Inter-wheel & Inter-axle | Inter-wheel & Inter-axle |
| Suspension/ Suspensi | ||
| Front/ Depan | Parabolic with stabilizer | Parabolic with stabilizer |
| Rear/ Belakang | Semi-elliptic tandem bogie with stabilizer | Semi-elliptic tandem bogie with stabilizer |
| Brake/ Rem | ||
| Main brake/ Rem utama | Full air, S-cam, dual circuit ABS | Full air, S-cam, dual circuit ABS |
| Additional brake/ Remtambahan | Engine & exhaust brake | Engine & exhaust brake |
| Dimension/ Dimensi | ||
| Wheelbase/ Jarak sumbu roda (mm) | 4,200 | 3,600 |
| Rear wheelbase/ Jarak sumbu roda belakang (mm) | 1,350 | 1,350 |
| Total length/ Panjang total (mm) | 7,760 | 7,460 |
| Total width/ Lebar total (mm) | 2,490 | 2,490 |
| Total height/ Tinggi total (mm) | 2,955 | 2,955 |
| Front overhang (FOH)/ Julur depan (mm) | 1,460 | 1,460 |
| Rear overhang (ROH)/ Julur belkang (mm) | 750 | 1,050 |
| Turning circle radius/ Radius putar (mm) | 9,150 | 8,750 |
| Ground clearance/ Jarak terendah ke tanah (mm) | 305 | 305 |
| Chassis weight/ Berat chassis | ||
| Kerb weight/ Berat kosong (kg) | 8,100 | 8,040 |
| GVW/ JBB (kg) | 26,500 | 26,500 |
| Feature/ Fitur | ||
| Feature/ Fitur | Cruise control, MP3 player, LED lamp, reverse buzzer | MP3 player, LED lamp, reverse buzzer |
